Technical Specifications
| Category | Specification |
|---|---|
| Input Sensor | Compatible with 3300 NSv non-contact proximity probe and extension cable (5m or 7m) |
| Power Supply | +12 to +35 VDC (two-wire configuration) |
| Output Signal | 4~20 mA linear signal, proportional to peak-to-peak vibration amplitude |
| Accuracy | ±1.5% over full scale with 250 Ω loop resistance |
| Max Loop Resistance | 1000 Ω at 35 VDC |
| Current Limiting | Typically 23 mA |
| Zero/Span Adjust | External non-interacting adjustments |
| Not OK/Signal Defeat | <3.6 mA within 100 µs of fault; restores in 2–3 seconds |
| Power-up Inhibit | Holds output <3.6 mA for 2–3 seconds on startup |
| Prox Out Output | 10 kΩ impedance, calibrated for 10 MΩ load |
| Linear Range | 1.4 mm starting at 0.25 mm from target |
| Incremental Scale Factor | 7.87 mV/µm ±6.5% typical |
| Frequency Response | 5 Hz to 6,000 Hz (+0/-3 dB) |
| Minimum Target Size | 9.5 mm diameter |
| Operating Temperature | -35°C to +85°C |
| Storage Temperature | -52°C to +100°C |
| Probe Temp Range | -52°C to +177°C (operating and storage) |
| Relative Humidity | 100% condensing, non-submerged |
| Mounting | DIN rail or bulkhead screw |
| Dimensions (L×W×H) | 100.1 × 73.9 × 53.3 mm |
| Weight | 0.43 kg (transmitter only), 0.82 kg (typical full system) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of sensor does the 990-04-70-02-00 transmitter support?
A1: It supports the Bently Nevada 3300 NSv non-contact eddy current probe and extension cable (5 m or 7 m).
Q2: What is the output signal of this transmitter?
A2: It outputs a 4–20 mA DC signal proportional to the peak-to-peak vibration amplitude.
Q3: Does it feature fault detection?
A3: Yes, it drives the output below 3.6 mA upon detecting a fault, restoring it in 2–3 seconds.
Q4: Can it output dynamic signals for diagnostics?
A4: Yes, via the “PROX OUT” terminal, and it is recommended to use the 122115-01 test adapter for isolation.
Q5: Are zero and span adjustments possible?
A5: Yes, they are manually adjustable using onboard potentiometers.
Q6: What environments is it suitable for?
A6: Designed for industrial use in wide temperature and high humidity (100% condensing) environments, typically for compressors, fans, and small motors.
Q7: What are the mounting options?
A7: It supports both DIN rail mounting and bulkhead screw mounting options.
Q8: Is the product approved for hazardous areas?
A8: Yes, it has multiple approvals including ATEX Zone 0/2 and CSA Division 2 certifications.
