Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions (L x W x H) | 100.1 x 73.9 x 53.3 mm |
| Weight | 0.43 kg |
| Input | Accepts 1 non-contacting 3300 NSv Proximity Probe and extension cable |
| Power Requirements | +12 to +35 Vdc input at the transmitter terminal |
| 4-20 mA Signal Output | 4 to 20 mA DC over full-scale range in 2-wire configuration |
| Accuracy | ±1.5% over specified full-scale range |
| Probe Gap | 0.5 to 1.75 mm (20 to 55 mils) |
| Maximum Loop Resistance | 1,000 Ω including cable at 35 Vdc |
| Temperature Range (Operating) | -35°C to +85°C (-31°F to +185°F) |
| Storage Temperature | -52°C to +100°C (-62°F to +212°F) |
| Humidity | 100% condensing, non-submerged |
| Frequency Response | 5 Hz to 6,000 Hz +0,3 dB |
| Transmitter Material | AISI 303 or 304 Stainless Steel (SST) |
FAQ
FAQs
Q1: What is the operating temperature range of the 990 Vibration Transmitter?
A1: The operating temperature range is from -35°C to +85°C (-31°F to +185°F).
Q2: How accurate is the 4-20 mA signal output?
A2: The 4-20 mA signal output has an accuracy of ±1.5% over the specified full-scale range.
Q3: What is the maximum loop resistance for the 990 transmitter?
A3: The maximum loop resistance is 1,000 Ω, including the cable at 35 Vdc.
Q4: Can the 990 transmitter be used in environments with high humidity?
A4: Yes, the transmitter can be used in environments with 100% condensing humidity, as long as the coaxial connectors are protected.
Q5: What kind of signal does the “Prox Out” provide?
A5: The “Prox Out” provides a dynamic vibration and gap voltage signal output for diagnostics, suitable for non-isolated test equipment.
Q6: What is the power supply requirement for the 990 transmitter?
A6: The transmitter requires a power supply of +12 to +35 Vdc at the transmitter terminal.
Q7: How long is the leadwire length for the proximity sensor output?
A7: The maximum leadwire length for the proximity sensor output (BNC connector) is 3 meters (10 feet).
Q8: Is the 990 transmitter suitable for use in hazardous areas?
A8: Yes, the 990 transmitter is certified for use in hazardous areas, including Zone 2 and Division 2 environments, with ATEX and IECEx approvals.
