Technical Specifications
| Category | Specification |
|---|---|
| Model | KJ2231X1-EA1 |
| Input Power | 24 VDC @ 70 mA |
| Relay Output | 30 VDC @ 2.5 A / 250 VAC @ 2.5 A |
| Operating Temperature | -40°C to +70°C |
| Shock Tolerance | 10g half sinewave for 11 ms |
| Vibration Resistance | 1mm peak-to-peak (2–13.2Hz); 0.7g (13.2–150Hz) |
| Air Contaminants | ISA-S71.04–1985 Class G3 |
| Relative Humidity | 5% to 95%, non-condensing |
| Maintenance | Not hot-swappable; no serviceable parts; no calibration required |
| Dimensions | 36 x 229 x 51 mm |
| Weight | 0.4 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the input power requirement for KJ2231X1-EA1?
A1: The module requires 24 VDC with a current draw of up to 70 mA.
Q2: What are the maximum relay output ratings?
A2: It supports up to 30 VDC or 250 VAC with a maximum current of 2.5 A.
Q3: What is the operating temperature range of this module?
A3: The module operates in environments ranging from -40°C to +70°C.
Q4: Can this module be inserted or removed while powered?
A4: No, unless the area is confirmed to be non-hazardous.
Q5: Does the module require calibration?
A5: No calibration is necessary; it is factory pre-configured.
Q6: How does the module perform under shock and vibration?
A6: It can withstand 10g shock and 0.7g vibration from 13.2 to 150Hz.
Q7: What level of air contamination is this module rated for?
A7: It complies with ISA-S71.04–1985 Class G3 for industrial environments.
Q8: Are there any user-serviceable parts in this module?
A8: No, the unit has no serviceable components and should not be disassembled.
