Technical Specifications
| Item | Specification |
|---|---|
| Model | KJ3222X1-EA1 |
| Product Type | Redundant Analog Input Terminal Block |
| Input Power | 30 VDC @ 200 mA |
| Operating Temperature | -40°C to +70°C |
| Shock | 10 g half-sine wave for 11 ms |
| Vibration | 2–13.2 Hz: 1 mm peak-to-peak; 13.2–150 Hz: 0.7 g |
| Air Contaminants | ISA-S71.04 –1985 Class G3 |
| Relative Humidity | 5% to 95% non-condensing |
| Explosion Protection | ATEX, IECEx, FM (see label for specifics) |
| Installation Notes | Cannot be inserted/removed under power |
| Dimensions (L×W×H) | 118 mm × 102 mm × 30 mm |
| Weight | 0.2 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Can the terminal block be hot-plugged?
A1: No. The KJ3222X1-EA1 cannot be inserted or removed with power applied.
Q2: What is the operating temperature range of this unit?
A2: It supports a wide range from -40°C to +70°C, suitable for harsh industrial settings.
Q3: Does this model support redundant configuration?
A3: Yes, it is designed for redundant analog input to enhance system reliability.
Q4: Is calibration required for this unit?
A4: No calibration is needed. The unit is factory-calibrated and maintenance-free.
Q5: How is environmental protection achieved?
A5: It complies with ISA-S71.04 Class G3 for airborne contaminants.
Q6: What explosion protection standards does it meet?
A6: It is certified under ATEX, IECEx, and FM standards for use in hazardous areas.
Q7: What are the maintenance requirements?
A7: The product is designed to be maintenance-free. No internal components are user-serviceable.
Q8: Is this unit suitable for high humidity environments?
A8: Yes, the KJ3222X1-EA1 can operate in environments with 5% to 95% relative humidity, non-condensing.
