Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | KJ3223X1-EA1 |
| Product Type | 16-Channel Analog Input Terminal Block |
| Input Power Rating | 30 VDC @ 100 mA |
| Operating Temperature | -40°C to +70°C |
| Shock Resistance | 10 g, half-sine wave for 11 ms |
| Vibration Resistance | 1 mm peak (2–13.2 Hz), 0.7 g (13.2–150 Hz) |
| Humidity | 5% to 95% RH, non-condensing |
| Airborne Contaminants | ISA-S71.04 Class G3 |
| Safety Certifications | ATEX, IECEx, FM (Zone 2, Class I Div. 2) |
| Removal Conditions | Cannot be inserted/removed under power |
| Calibration | Not required |
| User Serviceability | No user-serviceable parts |
| Dimensions (W x H x D) | 100 x 150 x 50 mm |
| Weight | 0.835 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the KJ3223X1-EA1 module?
A1: It serves as a 16-channel analog input terminal block for DeltaV Electronic Marshalling systems.
Q2: Can the module be hot-swapped while the system is running?
A2: No, the module must not be inserted or removed while power is applied.
Q3: Is calibration required for this module?
A3: No, calibration is not necessary.
Q4: What are the environmental limits for operation?
A4: It operates within -40°C to +70°C and 5–95% non-condensing humidity.
Q5: What kind of safety certifications does this module have?
A5: It has ATEX, IECEx, and FM approvals for use in hazardous areas (Zone 2, Class I Div. 2).
Q6: Does this module require maintenance?
A6: No user maintenance is required. The unit has no serviceable parts.
Q7: What type of airborne contaminants protection does it support?
A7: It is rated for ISA-S71.04 Class G3 environments.
Q8: What is the power requirement of the module?
A8: The module requires 30 VDC at 100 mA.
