Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PR6423/001-121 |
| Sensor Type | Non-contact Eddy Current Sensor |
| Tip Diameter | 8 mm |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% @ 0–45°C |
| Deviation from Straight Line (DSL) | ±0.025 mm (±1 mil) @ 0–45°C |
| Minimum Shaft Diameter | 25 mm (0.79 in) |
| Target Material | 42CrMo4 (AISI/SAE 4140) or custom |
| Operating Temperature | Sensor: -35°C to +180°C; Cable: -35°C to +150°C |
| Protection Class | IP66 (IEC 60529) |
| Material | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Nickel-plated brass |
| Dimensions | Thread: M10x1 or 3/8”-24UNF; Cable Ø: 2.8 mm (standard), 6 mm (armored) |
| Weight | Approx. 0.1 kg (100 g) with 1-meter cable |
FAQ
FAQ – Epro PR6423/001-121
Q1: What is the primary function of the PR6423/001-121 sensor?
A1: It measures dynamic displacement, position, eccentricity, and speed of rotating machinery shafts.
Q2: What is the sensing range of this sensor?
A2: The linear measurement range is 2 mm with an initial air gap of 0.5 mm.
Q3: What type of material should the target shaft be made of?
A3: The standard target is ferromagnetic steel 42CrMo4; other materials are supported upon request.
Q4: Is this sensor certified for use in hazardous areas?
A4: Yes, it complies with ATEX, IECEx, CSA, and UL standards for intrinsic safety and non-sparking zones.
Q5: What are the environmental limits of this sensor?
A5: It operates in environments from -35°C to +180°C for the sensor body and up to +150°C for the cable.
Q6: What is the weight of the sensor including cable?
A6: Approximately 100 grams (0.1 kg) with a 1-meter cable.
Q7: Does it support armored cable options?
A7: Yes, both standard and armored cable options are available.
Q8: Is the sensor suitable for nuclear environments?
A8: A special RAD version is available, resistant to radiation up to 80 Mrad.
