Technical Specifications
| Parameter | Specification |
|---|---|
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% (0 to +45°C) |
| Deviation from Best Fit Line (DSL) | ±0.025 mm (±1 mil) (0 to +45°C) |
| Minimum Shaft Diameter | 25 mm (0.98 in) |
| Target Material | 42CrMo4 (AISI/SAE 4140), others on request |
| Protection Class | IP66 (IEC 60529) |
| Operating Temperature (Sensor + Cable) | -35°C to +180°C (-31°F to 356°F) |
| Operating Temperature (Cable & Connector) | -35°C to +150°C (-31°F to 302°F) |
| Sensor Tip Material | PEEK (Polyether Ether Ketone) |
| Case Material | Stainless Steel |
| Cable Material | PTFE (Polytetrafluoroethylene) |
| Connector Material | Nickel-plated Brass |
| Weight (Sensor + 1m Cable) | Approx. 100 g (0.1 kg) |
| Sensor Head Diameter | 8 mm |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the measurement range of the PR6423/011-000 sensor?
A1: The linear measurement range is 2 mm (80 mils).
Q2: What is the initial gap required for optimal performance?
A2: The initial air gap is 0.5 mm (20 mils).
Q3: What is the minimum shaft diameter this sensor can detect?
A3: The minimum measurable shaft diameter is 25 mm (0.98 in).
Q4: What materials is the sensor made from?
A4: The sensor tip is PEEK, the case is stainless steel, the cable is PTFE, and the connector is nickel-plated brass.
Q5: What are the operating temperature limits of the sensor?
A5: The sensor can operate between -35°C and +180°C.
Q6: Does the sensor have hazardous area certifications?
A6: Yes, it is compliant with ATEX, IEC-Ex, and CSA standards for intrinsic safety and non-sparking applications.
Q7: What is the deviation from linearity (DSL) of this sensor?
A7: It is ±0.025 mm (±1 mil) over the temperature range of 0 to +45°C.
Q8: What is the weight and size of the sensor head?
A8: The sensor head is 8 mm in diameter and weighs approximately 0.1 kg including 1m cable.
