Technical Specifications
| Parameter | Details |
|---|---|
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor | 8 V/mm (203.2 mV/mil) ±5%, within 0 to 45°C |
| Deviation from Straight Line | ±0.025 mm (±1 mil), within 0 to 45°C |
| Minimum Shaft Diameter | 25 mm (0.79 in) |
| Target Material | 42CrMo4 (AISI/SAE 4140), others on request |
| Protection Class | IP66, compliant with IEC 60529 |
| Operating Temperature | Sensor + 1m cable: -35°C to +180°C; Cable/Connector: -35°C to +150°C |
| Material | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Nickel-plated brass |
| Certifications | ATEX, IEC-Ex, CSA, UL, etc. |
| Hazardous Area Approval | Intrinsic Safety (ia), Non-sparking (nA); T6 (≤64°C), T4 (≤114°C), T3 (≤160°C) |
| Case Thread | M10x1 or 3/8″-24 UNF |
| Cable Diameter | Standard: 2.8 mm; Armored: 6 mm |
| Minimum Bending Radius | Standard: 25 mm; Armored: 35 mm |
| Connector Type | Lemo 11 mm diameter or open end |
| Sensor Tip Diameter | 8 mm |
| Weight | Approx. 0.1 kg (with 1m cable) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What machinery is this sensor suitable for?
A1: It is designed for critical rotating machinery like turbines, compressors, gearboxes, pumps, and fans.
Q2: What physical parameters can it measure?
A2: It measures radial and axial shaft dynamic displacement, position, eccentricity, and speed.
Q3: Is the sensor certified for hazardous areas?
A3: Yes, it holds ATEX, IEC-Ex, and CSA certifications for Intrinsic Safety and Non-sparking areas.
Q4: What is the minimum shaft diameter supported?
A4: The minimum target shaft diameter is 25 mm.
Q5: What is the maximum operating temperature?
A5: The sensor can withstand up to +180°C; cable and connector up to +150°C.
Q6: Is the sensor resistant to corrosion?
A6: Yes, it uses stainless steel and PEEK materials, offering excellent corrosion resistance.
Q7: Is there a radiation-resistant version available?
A7: Yes, the PR6423/xxx-xxx-RAD variant is radiation-resistant up to 80 Mrad.
Q8: Does this model support armored cable?
A8: Yes, PR6423/01C-030 includes armored cable for improved mechanical and EMI protection.
