Technical Specifications
| Parameter | Description |
|---|---|
| Sensor Tip Diameter | 8 mm |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor | 8 V/mm (203.2 mV/mil) ±5% from 0 to 45°C |
| Deviation from Linearity | ±0.025 mm (±1 mil) from 0 to 45°C |
| Minimum Shaft Diameter | 25 mm (0.79 in) |
| Target Material | Standard: 42CrMo4 (AISI/SAE 4140); others available on request |
| Protection Class | IP66, IEC 60529 |
| Operating Temperature | Sensor (with 1m cable): -35 to +180°C; Cable: up to +150°C |
| Material | Tip: PEEK; Case: Stainless Steel; Cable: PTFE; Connector: Brass (nickel-plated) |
| Weight (incl. 1m Cable) | Approx. 0.1 kg (100 grams) |
| Thread Type | 3/8″-24 UNF |
| Standard Cable Diameter | 2.8 mm; Min. bend radius: 25 mm |
| Armored Cable Diameter | 6 mm; Min. bend radius: 35 mm |
| Connector | Lemo (11 mm dia.) or open cable end |
FAQ
Frequently Asked Questions (FAQ)
Q1: What are the typical applications of PR6423/10R-040?
A1: It is typically used for dynamic shaft displacement, position, eccentricity, and speed monitoring in turbines, compressors, gearboxes, pumps, and fans.
Q2: Does this sensor have hazardous area approvals?
A2: Yes, it is certified for ATEX, IECEx, and CSA intrinsic safety and non-sparking applications, depending on the converter used.
Q3: Can it operate in high-temperature environments?
A3: Yes, the sensor can withstand up to +180°C, and the cable/connector up to +150°C.
Q4: What is the minimum shaft diameter the sensor can detect?
A4: The minimum detectable shaft diameter is 25 mm.
Q5: Is the cable length customizable?
A5: Yes, options include 4m, 5m, 8m, 9m, and 10m cable lengths based on the ordering code.
Q6: Is there a radiation-hardened version available?
A6: Yes, the PR6423/xxx-xxx-RAD version is designed for radiation environments.
Q7: Is the output signal linear and standardized?
A7: Yes, it offers a linear output of 8 V/mm with ±5% accuracy.
Q8: Is the material suitable for harsh industrial environments?
A8: Yes, the stainless-steel casing offers corrosion resistance for industrial use.
