Technical Specifications
| Parameter | Value |
|---|---|
| Output | 1 AC cycle per revolution/gear tooth |
| Rise/Fall Time | 1 µs |
| Output Voltage | High >10 V / Low <1 V (12 VDC @ 100 kΩ load) |
| Air Gap | 1 mm (Module 1), 1.5 mm (Module ≥2) |
| Max Operating Frequency | 12 kHz (720,000 cycles per minute) |
| Trigger Mark | Limited to spur gear and involute gearing (Module 1) |
| Target Material | Magnetic soft iron or steel (non-stainless steel) |
| Material | Sensor – Stainless steel; Cable – PTFE |
| Operating Temp Range | -25 to 100°C |
| Storage Temp Range | -40 to 100°C |
| Reference Temperature | 25°C |
| Sealing Rating | IP67 |
| Power Supply | 10 to 30 VDC @ max. 25mA |
| Resistance | Max. 400 Ohms |
| Certifications | CE 2014/30/EU, 2014/35/EU, 2011/65/EU |
| Dimensions (Diameter) | 14 mm |
| Weight (Sensor Only) | 0.21 kg (210 grams) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum detection frequency supported by PR9376/010-011?
A1: It supports up to 12 kHz (720,000 counts per minute).
Q2: What types of equipment is this sensor suitable for?
A2: It is suitable for steam turbines, gas turbines, hydro turbines, compressors, pumps, and fans.
Q3: What is the output voltage range of the sensor?
A3: With 12VDC and 100 kΩ load, output is >10V high and <1V low.
Q4: What is the operating temperature range of the PR9376 sensor?
A4: It can operate from -25°C to 100°C.
Q5: What materials should be used as targets?
A5: Magnetic soft iron or plain steel is recommended. Do not use stainless steel.
Q6: How is the sensor mounted?
A6: It is typically mounted with a bracket, maintaining specified air gap: 1mm for Module 1, 1.5mm for Module ≥2.
Q7: What are the power requirements for the PR9376?
A7: It requires 10–30 VDC with a maximum current of 25mA.
Q8: What is the environmental protection rating?
A8: The sensor is rated IP67, suitable for dusty and splash-prone industrial environments.
