Technical Specifications
| Parameter Category | Description |
|---|---|
| Product Name | VersaMax Discrete Output Module IC200MDL742H |
| Output Type | Positive Logic Discrete Output |
| Number of Output Points | 32 points |
| Output Voltage Range | 18–30 VDC (nominal 24 VDC) |
| Load Current per Point | 0.5 A max (resistive), 2 A inrush max for 100 ms |
| Grouping | 2 groups of 16 points |
| Channel-to-Channel Isolation | None |
| Response Time | ON: 0.5 ms, OFF: 0.5 ms |
| Output Protection | Short circuit protection, overcurrent protection, free-wheeling diodes |
| External Power Supply | 18–30 VDC, nominal 24 VDC |
| Backplane Current (5V) | 150 mA max |
| Module Dimensions (W×H×D) | 110 × 66.8 × 50 mm (excluding carrier and connectors) |
| Module Weight | 0.15 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many output points does the module have?
A1: The IC200MDL742H module provides 32 discrete output points.
Q2: What is the maximum output current per point?
A2: Each point can deliver up to 0.5 A with an inrush current capacity of 2 A for 100 ms.
Q3: Does the module have channel-to-channel isolation?
A3: No, the module does not provide channel-to-channel isolation.
Q4: What is the supported voltage range for the output?
A4: The output voltage range is 18 to 30 VDC, with a nominal value of 24 VDC.
Q5: What is the switching response time of the module?
A5: The response time is 0.5 ms for both ON and OFF transitions.
Q6: Is the module protected against short circuits or overcurrent?
A6: Yes, each output has built-in short-circuit and overcurrent protection, including free-wheeling diodes.
Q7: What are the physical dimensions of the module?
A7: The dimensions are 110 × 66.8 × 50 mm (excluding the carrier and mating connectors).
Q8: What type of carrier is required for installation?
A8: The module requires a carrier base such as IC200CHS002 for proper installation.
