Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | IC693MDL750 |
| Product Series | GE Series 90-30 |
| Module Type | Negative Logic Digital Output Module |
| Number of Outputs | 32 points (grouped per channel) |
| Output Type | Negative logic (sinking type) |
| Voltage Range | 5 to 30 VDC |
| Rated Voltage | 24 VDC |
| Max Current/Point | 0.5 A |
| Max Current/Channel | 4 A |
| Response Time | 0.2 ms ON and OFF |
| Isolation Voltage | 1500 VDC (channel to logic) |
| Connector Type | 50-pin female connector |
| Mounting | Plug-in, rack-mounted |
| Operating Temp | 0 to 60°C |
| Storage Temp | -40 to 85°C |
| Dimensions (W×D×H) | 142 x 30 x 130 mm |
| Weight | 0.25 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of output does the IC693MDL750 module provide?
A1: It provides negative logic (sinking) outputs.
Q2: What is the maximum current per output point?
A2: Each output point can handle up to 0.5 A.
Q3: Does the module have optical isolation?
A3: Yes, it features 1500 VDC isolation between channel and logic.
Q4: How is the module connected to field devices?
A4: It uses a 50-pin female connector.
Q5: What systems is the IC693MDL750 compatible with?
A5: It is compatible with GE Series 90-30 PLC systems.
Q6: What is the response time of this module?
A6: The response time is 0.2 milliseconds for both ON and OFF operations.
Q7: Is the module hot-swappable?
A7: No, power must be turned off before installation or removal.
Q8: What is the operational temperature range?
A8: It operates within a temperature range of 0°C to 60°C.
