Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | DC Voltage Output Module |
| Voltage Type | 12/24 VDC Positive Logic Output |
| Number of Channels | 32 points |
| Output Type | Sourcing (positive logic) |
| Max Load per Point | 0.5 A |
| Total Load | Limited per module circuitry and wiring regulations |
| Response Time | Typical ON/OFF delay is 0.2 milliseconds |
| Output Protection | Includes overcurrent and reverse polarity protection |
| Isolation | Optical isolation from logic circuitry |
| Mounting | Installed in GE Fanuc Series 90-30 PLC rack |
| Power Requirement | Supplied via PLC backplane |
| LED Indicators | Individual LED for each output point |
| Dimensions (W x H x D) | 63.5 x 127 x 146 mm |
| Weight | 0.68 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the output voltage range of the IC693MDL753 module?
A1: The module supports 12 VDC and 24 VDC positive logic output.
Q2: What is the maximum current per output point?
A2: Each output point can handle up to 0.5 A.
Q3: How many output channels does the module have?
A3: The module provides 32 output points.
Q4: What is the output signal type?
A4: It uses sourcing (positive logic) output.
Q5: Does the module include short-circuit protection?
A5: It has overcurrent protection; external fusing is still recommended.
Q6: Can this module be hot-swapped?
A6: No, power must be off when inserting or removing the module.
Q7: How is the output status indicated for each point?
A7: Each output point is equipped with an LED status indicator.
Q8: Does the module require external power?
A8: No, power is drawn from the PLC backplane.
