Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Relay Output Module |
| Number of Points | 16 Points (independent relay outputs) |
| Contact Type | Form C (SPDT – NO and NC contacts) |
| Rated Voltage per Point | Up to 30 VDC / 250 VAC |
| Rated Current per Point | Max 2A (resistive), 0.4A (inductive) |
| Relay Type | SPDT mechanical relay |
| Isolation | 1500 V rms point-to-logic |
| Max Response Time | Pickup: 15ms; Dropout: 15ms |
| Channel Isolation | Each output point is electrically isolated |
| Power Supply | Supplied by Series 90-30 base rack |
| Dimensions (W×H×D) | 142 × 30 × 130 mm |
| Weight | 0.25 kg |
| Mounting | Plug-in to Series 90-30 rack |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many output points are available on the IC693MDL760 module?
A1: The module provides 16 independent relay output points.
Q2: Are the relays normally open or normally closed?
A2: Each point uses Form C (SPDT) relays, which include both normally open (NO) and normally closed (NC) contacts.
Q3: What is the maximum current per output point?
A3: The maximum is 2A for resistive loads and 0.4A for inductive loads.
Q4: Are the output channels electrically isolated from each other?
A4: Yes, all points are fully isolated from each other for safety and reliability.
Q5: Does the module support both DC and AC loads?
A5: Yes, it supports up to 30VDC or 250VAC loads, suitable for solenoid valve control.
Q6: What is the relay switching time?
A6: Pickup and dropout time are both approximately 15ms.
Q7: Is external power required for relay operation?
A7: No, power is supplied by the Series 90-30 rack.
Q8: What are the physical dimensions and weight of the module?
A8: Dimensions are 142 x 30 x 130 mm and the weight is 0.25 kg.
