Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Isolated Relay Output Module |
| Number of Outputs | 8 points (individually isolated) |
| Output Type | Relay (dry contact) |
| Rated Voltage | 5–30 VDC / 5–250 VAC |
| Maximum Load Current | 2 A per point (resistive), 4 A total max |
| Rated Load | 60W (30VDC) / 62.5VA (250VAC) |
| Response Time (On/Off) | 10 ms max |
| Isolation | Optical isolation per point, 1500V RMS logic |
| Status Indicators | Individual LED indicators per point |
| Operating Temperature | 0 to 60°C |
| Mounting | Mounted on IC693 base unit |
| Dimensions | 142 x 30 x 130 mm |
| Weight | 0.25 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Are the output points on the IC693MDL916 fully isolated?
A1: Yes, each output point is fully isolated, ensuring enhanced safety and system integrity.
Q2: Does the module support both AC and DC loads?
A2: Yes, the IC693MDL916 supports loads ranging from 5–250 VAC or 5–30 VDC.
Q3: What is the maximum current rating per output point?
A3: The maximum current is 2 A per point, with a total module current limit of 4 A.
Q4: What types of loads can the module drive?
A4: The module is ideal for driving resistive loads such as lamps, solenoids, and small relays.
Q5: Does each output point have a status indicator?
A5: Yes, each point has a corresponding LED status indicator on the front panel.
Q6: How is the module installed?
A6: It mounts on the I/O base unit of the GE Series 90-30 system.
Q7: What is the response time, and is it suitable for time-critical systems?
A7: The response time is up to 10 ms, suitable for applications not requiring high-speed switching.
Q8: What signal types are supported?
A8: It provides dry contact relay outputs, suitable for controlling low-speed electrical devices.
