Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | IC693PWR330 |
| Input Voltage Range (AC) | 85 to 264 VAC (50/60 Hz) |
| Input Voltage Range (DC) | 100 to 300 VDC |
| Input Power | 100 VA (AC input); 50 W (DC input) |
| Inrush Current | 4A peak, max 250 ms |
| Total Output Power | Max 30 W (combined for all outputs) |
| +5VDC Output | Max 30 W (5.0 VDC to 5.2 VDC) |
| +24VDC Isolated Output | Max 20 W (22.5 VDC to 28 VDC) |
| +24VDC Relay Output | Max 5 W (24 VDC to 28 VDC) |
| Overvoltage Protection | +5VDC output: 6.4 to 7 V |
| Overcurrent Protection | +5VDC output: max 7 A |
| Hold-up Time | Minimum 20 ms |
| Dimensions | 150 × 120 × 130 mm |
| Weight | 0.544 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the IC693PWR330 support both AC and DC input?
A1: Yes, it supports a wide input range of 85–264 VAC or 100–300 VDC.
Q2: Can all output channels be fully loaded simultaneously?
A2: No, the combined output power must not exceed 30W.
Q3: What is the maximum load for the +5VDC output?
A3: Up to 30W, limited to a maximum of 7A.
Q4: Can the +24VDC relay output power external devices?
A4: Yes, but the output power must not exceed 5W.
Q5: Is the isolated +24VDC output available for external use?
A5: Yes, it can power external circuits such as 24VDC input modules.
Q6: What happens if the +24VDC isolated output is shorted?
A6: The controller will shut down; overloading or shorting should be avoided.
Q7: Does the module include input overvoltage protection?
A7: Yes, it has built-in overvoltage protection enabled via a grounding jumper.
Q8: What should be done before Hi-pot testing?
A8: The overvoltage protection jumper must be removed before testing and reinstalled afterward.
