Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693PWR331 |
| Input Voltage Range (Start) | 8 to 30 VDC |
| Input Voltage Range (Run) | 2 to 30 VDC |
| Rated Input Power | 50 watts (max at full load) |
| Output Voltage – +5 VDC | 5.0 to 5.2 VDC |
| Output Power – +5 VDC | Max 30 watts |
| Output Voltage – +24 VDC Relay | 9.2 to 28.8 VDC |
| Output Power – +24 VDC Relay | Max 5 watts |
| Output Voltage – +24 VDC Isolated | 9.2 to 28.8 VDC |
| Output Power – +24 VDC Isolated | Max 20 watts |
| Total Output Power Limit | 30 watts (combined for all outputs) |
| Overvoltage Protection | +5 VDC output: 6.4 to 7 V |
| Overcurrent Protection | +5 VDC output: 7 A maximum |
| Holdup Time | Minimum 0 ms |
| Dimensions (W × H × D) | 150 × 120 × 130 mm |
| Weight | 0.54 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the total maximum output power of the IC693PWR331?
A1: The total combined output power is limited to 30 watts.
Q2: What is the input voltage range required for normal operation?
A2: The power supply operates between 2 VDC to 30 VDC, but requires at least 8 VDC to start.
Q3: Can the isolated +24 VDC output be used for external devices?
A3: Yes, it can power external 24 VDC input modules within the 20W limit.
Q4: What happens if the isolated 24 VDC output is shorted?
A4: The PLC operation will halt if this output is overloaded or short-circuited.
Q5: What protections are built into the +5 VDC output?
A5: Overvoltage protection (6.4–7 V) and overcurrent protection (up to 7 A).
Q6: How should the power supply be wired to a DC source?
A6: Connect + to the top terminal, – to the second, and ground to the third terminal.
Q7: What is the maximum current supported on the +5 VDC output?
A7: Up to 6 A under normal conditions, with 7 A as the overcurrent threshold.
Q8: Does the power supply require derating at high temperatures?
A8: Yes, derating is necessary above 50°C ambient temperature.
