Technical Specifications
| Parameter | Value |
|---|---|
| Model | F3315 |
| System | Planar F |
| Function | (Ex i) Intrinsically Safe Switching Amplifier |
| Number of Channels | 4 channels |
| Operating Voltage | 25 VDC |
| Power Consumption | Max. 3 W |
| Safety Circuit | RC 6 certified safety switching |
| Compatibility | Functionally compatible with Planar F modules |
| Intrinsic Safety | Certified for Ex i (intrinsically safe) use |
| Dimensions (W×H×D) | 200 × 100 × 25 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many output channels does the F3315 module have?
A1: The F3315 module provides 4 intrinsically safe output channels.
Q2: What is the maximum operating voltage of the F3315?
A2: The module is rated for 25 VDC operation.
Q3: Is the F3315 suitable for hazardous areas?
A3: Yes, it is Ex i certified, suitable for Zone 1/2 hazardous environments.
Q4: Does the F3315 support redundancy?
A4: The F3315 does not have built-in redundancy. Redundancy must be implemented at the system level.
Q5: What is the installation type of the module?
A5: It is designed for standard Planar F slot-type installation, allowing easy replacement and maintenance.
Q6: Is the module ATEX or SIL certified?
A6: The module has Ex i certification; SIL compliance depends on the overall system setup.
Q7: Can the F3315 replace the older F3304 model?
A7: Yes, the F3315 is the recommended replacement for the F3304, offering double the number of inputs.
Q8: When was the F3315 discontinued, and is there a replacement?
A8: The F3315 was officially discontinued on March 31, 2022. Suggested replacements include models like F3324, depending on the application.
