Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | HIMA F3328 |
| Product Type | Safety System Input Module |
| Number of Channels | 8 channels (independent safety input) |
| Input Type | Digital input (potential-free contacts) |
| Voltage Range | 18 VDC to 30 VDC |
| Input Current | Approx. 3 mA per channel |
| Input Filtering | Configurable filtering time |
| Isolation | Channel-to-channel and system bus isolation |
| Safety Integrity | SIL 3 (compliant with IEC 61508) |
| Communication | Compatible with HIMA Planar F bus |
| Mounting | Standard DIN rail |
| Dimensions | 120 x 160 x 40 mm |
| Weight | 0.2 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | Max. 95%, non-condensing |
| EMC Compliance | Meets EN 61000 standards |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of input signal is supported by the F3328 module?
A1: The F3328 module supports digital inputs via potential-free contacts, suitable for switches, pushbuttons, etc.
Q2: How many input channels does the F3328 module have?
A2: It provides 8 independent safety input channels with galvanic isolation between them.
Q3: Is the F3328 module certified for SIL applications?
A3: Yes, it complies with SIL 3 according to IEC 61508 safety standards.
Q4: What is the recommended power supply voltage for the module?
A4: The input voltage range is 18 VDC to 30 VDC.
Q5: What are the dimensions and weight of the F3328 module?
A5: The module measures 120 x 160 x 40 mm and weighs approximately 0.2 kg.
Q6: How is the F3328 module installed?
A6: It is designed for easy DIN rail mounting in standard control cabinets.
Q7: Can the module operate in harsh environments?
A7: Yes, it is designed to operate reliably between 0°C and 60°C.
Q8: Does the module support input signal filtering?
A8: Yes, it features configurable input filtering to reduce noise and interference.
