Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | F3405 |
| Type | 4-Channel Fail-Safe Relay Amplifier Module |
| Number of Channels | 4 |
| Relay Type | Fail-safe, Electromechanical |
| Contact Configuration | 2 NO (Normally Open) contacts per channel |
| Rated Voltage | 24 V DC nominal |
| Input Signal | From safe control system |
| Output Contacts | Floating, potential-free |
| Switching Capacity | 250 V AC / 6 A or 30 V DC / 6 A |
| Electrical Isolation | Galvanic isolation between channels |
| Diagnostic Functions | Channel-specific monitoring |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +85°C |
| Mounting Type | DIN rail mounting |
| Dimensions (W x H x D) | 198 × 162 × 108 mm |
| Weight | 1.2 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the F3405 module?
A1: The F3405 module amplifies safety-related relay signals in four independent fail-safe channels.
Q2: Is the F3405 suitable for redundant safety systems?
A2: Yes, it is designed for use in HIMA’s safety-related control systems with redundancy capability.
Q3: What kind of signals does the module handle?
A3: It handles binary input signals and provides relay output with potential-free contacts.
Q4: Can each channel be diagnosed independently?
A4: Yes, the module provides independent diagnostics for each channel.
Q5: What type of mounting does the F3405 support?
A5: It is designed for DIN rail mounting inside control cabinets.
Q6: What is the electrical isolation configuration?
A6: Each channel is galvanically isolated from the others and from the system.
Q7: What is the maximum switching capacity of each relay?
A7: Each relay can switch up to 250 V AC / 6 A or 30 V DC / 6 A.
Q8: Can the F3405 operate in high-temperature environments?
A8: It can operate in temperatures from 0°C to +60°C.
