Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | F3417A |
| Product Series | Planar F System |
| Module Type | Relay Amplifier Module |
| Mounting Method | DIN rail mounting |
| Signal Type | Digital output |
| Operating Voltage | 24 VDC |
| Output Channels | 1 relay output |
| Output Capacity | Up to 2A @ 24 VDC |
| Response Time | <10 ms |
| Isolation Voltage | ≥ 500 VDC |
| Operating Temp. | 0°C to +60°C |
| Storage Temp. | -25°C to +85°C |
| Dimensions | 120 x 50 x 110 mm |
| Weight | 0.399 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the F3417A module?
A1: The F3417A functions as a relay amplifier, converting control signals into isolated high-power switching signals.
Q2: What is the output capacity of the module?
A2: The module supports up to 2A output current at 24VDC.
Q3: How many output channels does the F3417A provide?
A3: It provides a single relay output channel.
Q4: In what systems can this module be used?
A4: It is designed for HIMA’s Planar F safety systems, mainly used in industrial automation and safety-critical control applications.
Q5: How is the module installed?
A5: It is mounted on a DIN rail, making it easy to install in control panels.
Q6: Does the module offer electrical isolation?
A6: Yes, it provides electrical isolation above 500 VDC for safe operation.
Q7: Can the module operate in high-temperature environments?
A7: The operating temperature range is from 0°C to +60°C.
Q8: Is hot-swapping supported by this module?
A8: No, the F3417A does not support hot-swapping. Power must be turned off before replacement.
