Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | F3423 |
| Brand | HIMA |
| Module Type | Relay Amplifier Module |
| System Platform | Planar F System |
| Mounting Method | DIN rail mounting |
| Input Channels | 2 channels |
| Output Type | Electrically isolated relay |
| Relay Contact Rating | Max 250 V AC / 6 A |
| Operating Voltage | 24 V DC |
| Power Consumption | Approx. 1.2 W |
| Response Time | ≤10 ms |
| Redundancy Support | Supported |
| Certification | IEC 61508 compliant, SIL 3 |
| Dimensions | 120 x 50 x 110 mm |
| Weight | 0.399 kg |
| Operating Temp Range | 0°C to +60°C |
| Storage Temp Range | -25°C to +85°C |
| Protection Class | IP20 |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many input channels does the F3423 module support?
A1: It supports two input channels for independent relay control.
Q2: How is electrical isolation achieved in the module?
A2: Electrical isolation between input and output is provided via internal relays.
Q3: Does the F3423 support redundant operation?
A3: Yes, it supports redundancy for use in high-availability systems.
Q4: What is the maximum relay contact capacity?
A4: Each contact can handle up to 250 V AC / 6 A.
Q5: Is the module certified to any safety standard?
A5: Yes, it is IEC 61508 certified and supports SIL 3.
Q6: What is the recommended temperature range for operation?
A6: Operating temperature is 0°C to +60°C; storage is -25°C to +85°C.
Q7: What are the dimensions and weight of the F3423 module?
A7: The module measures 120 x 50 x 110 mm and weighs 0.399 kg.
Q8: What types of systems is the F3423 suitable for?
A8: It is widely used in high-safety automation environments such as petrochemical, power generation, and metallurgy industries.
