Technical Parameters
| Item | Specification |
|---|---|
| Digital Inputs | 24 channels (non-isolated) |
| Digital Outputs | 8 channels (non-isolated, common ground L-) |
| Analog Inputs | 8 channels (0–10 V or 0–20 mA via external shunt) |
| Safety Counters | 2 channels, 24-bit, max 100 kHz |
| Power Supply Voltage | 24 VDC, -15% to +20% |
| Max Current Consumption | Idle: 0.5 A; Max: up to 9 A |
| External Fuse | 10 A time-lag fuse |
| Ethernet Interfaces | 4 x RJ45, 10/100Base-T, auto-negotiation/crossover |
| Communication Protocols | safeethernet, Modbus TCP, OPC, EtherNet/IP (not for SILworX) |
| Analog Input Resolution | 12 bit |
| Digital Input Accuracy | max ±1% |
| Analog Input Accuracy | max ±0.5%, safety-related accuracy ±2% |
| Operating Temperature | 0…+60 °C |
| Storage Temperature | -40…+85 °C |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 257 × 114 × 97 mm |
| Weight | 1.2 kg |
FAQ
Frequently Asked Questions
Q1: What types of input signals are supported by the F35 controller?
A1: It supports 24 digital inputs (0–30 V threshold configurable) and 8 analog inputs (0–10 V or 0–20 mA with external shunt adapter).
Q2: What is the maximum current load for the output channels?
A2: Channels 1–3 and 5–7 support up to 0.5 A at 60°C; channels 4 and 8 support up to 1 A (2 A at 50°C).
Q3: Is the controller certified for functional safety?
A3: Yes, the F35 is TÜV-certified and meets IEC 61508 SIL3, IEC 62061, and EN ISO 13849-1 PL e standards.
Q4: Which communication protocols are supported?
A4: Supported protocols include safeethernet, Modbus TCP, OPC, and EtherNet/IP (EtherNet/IP not supported in SILworX environment).
Q5: Does the analog input support line fault detection?
A5: Analog input channels do not monitor for line faults by default but fault conditions can be handled via software logic using status codes.
Q6: What are the environmental requirements for installation?
A6: Operating temperature range is 0…+60 °C with IP20 protection; avoid high humidity or corrosive environments.
Q7: What are the power supply requirements?
A7: Use a PELV or SELV 24 VDC power source with safe isolation and protect with a 10 A time-lag fuse.
Q8: Is the controller suitable for use in hazardous zones?
A8: Yes, it is compliant with ATEX Zone 2 when installed in an enclosure that meets EN 60079-15 requirements and follows all specified conditions.
