Product Specifications
| Specification | Details |
| Product Number | 05701-A-0325 |
| Product Type | DC Input Card |
| Nominal DC Input | 24V DC |
| Dimensions (L × W × H) | 112 × 25 × 102 mm |
| Weight | 0.129 kg |
| Fuse Protection | Yes |
| Terminal Block | Two-part (TB1) |
| RFI Filtering | Yes |
| Reverse Polarity Protection | Yes |
| Auxiliary DC Input | Yes (for Backup Battery) |
| Isolation | PSU and AUX isolated by diodes |
Product Introduction
The Honeywell 05701-A-0325 DC Input Card is designed to supply DC power to a rack via a nominal 24V DC input. This input is connected from an external power supply and routed through the Engineering Card and sub-rack backplane to all connected cards in the rack. Protection against overcurrent is provided by a fuse located on the DC Input Card. Additionally, the product includes reverse polarity protection and RFI filtering, ensuring the stability and reliability of the system.
The card also features a two-part terminal block (TB1), which simplifies the process of removing the card without needing to disconnect each of the connected wires. For installations that use more than eight Honeywell 5704 Catalytic Cards, the use of a Quad Relay Interface Card to power the Control Cards is recommended to prevent excessive current flow through the backplane. A backup battery supply can also be connected to the auxiliary DC input connections for continuous operation.
