Technical Specifications
| Item | Description |
|---|---|
| Model | 8C-PAIH52 |
| Part Number | 51307070-175 |
| Type | Analog Output Module |
| Output Channels | 8 Single-ended Channels |
| Output Signal Type | 4–20 mA with HART |
| Accuracy | ±0.05% of Full Scale |
| Resolution | 16-bit |
| Isolation Voltage | 1500 V AC Channel-to-System Isolation |
| Communication | HART supported per channel |
| Power Supply | 24 V DC |
| Operating Temp | 0°C to 60°C |
| Storage Temp | -40°C to 70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Redundancy | Redundancy Supported |
| Mounting Type | Mounted on IOTA Base |
| Dimensions | 157 x 106 x 35 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What output signal type does the 8C-PAIH52 support?
A1: It supports 4–20 mA analog output with HART communication.
Q2: Is HART communication supported on all channels?
A2: Yes, each channel supports HART protocol.
Q3: Does the 8C-PAIH52 support redundancy?
A3: Yes, it can be used in redundant configurations.
Q4: Is there isolation between the channels and the system?
A4: Yes, the module provides 1500 V AC isolation between channels and the system.
Q5: What type of base does the module mount on?
A5: It mounts on an IOTA (Input/Output Terminal Assembly) base.
Q6: What is the output accuracy of the module?
A6: The output accuracy is ±0.05% of full scale.
Q7: What is the operating temperature range?
A7: The module operates in a temperature range of 0°C to 60°C.
Q8: Does this module support hot-swapping?
A8: Yes, it supports hot-swap operation without shutting down the system.
