Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8C-PAOH51 |
| Module Type | High-Level Analog Output with HART |
| Output Type | 4-20 mA current loop |
| Number of Output Channels | 16 channels |
| Resolution | ±0.05% of full scale |
| Calibrated Accuracy | ±0.35% of full scale (25°C including linearity) |
| Output Current Linearity | ±0.05% of full scale |
| Output Readback Accuracy | ±4% of full scale |
| Settable Output Current Range | 0 mA, 2.9 mA to 21.1 mA |
| Max Resistive Load | 800 ohms (24V supply) |
| Max Output Voltage | 16 V (with 24V supply) |
| Open Circuit Voltage | 22 V |
| Response Time | ≤ 80 ms to 1% of final value |
| Output Temperature Drift | 0.005% of full scale per °C |
| Output Ripple | < 100 mV peak-to-peak across 250Ω load |
| Redundancy Support | Yes |
| HART Protocol Support | Yes |
| Dimensions (W x H x D) | 157 x 106 x 35 mm |
| Weight | 0.47 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many analog output channels does the module support?
A1: It supports up to 16 analog 4-20 mA output channels.
Q2: Does the module support HART communication?
A2: Yes, it supports HART for both configuration and status reporting.
Q3: Is redundancy supported?
A3: Yes, the module supports redundancy for increased reliability.
Q4: What is the typical response time of the module?
A4: The output settles within 1% of the final value in approximately 80 milliseconds.
Q5: What is the maximum load resistance supported?
A5: The module supports up to 800 ohms load.
Q6: What is the settable output current range?
A6: The settable output range is 0 mA, 2.9 mA to 21.1 mA.
Q7: Does the module support open wire detection?
A7: Yes, it includes open wire detection and provides channel soft failure alarms.
Q8: What are the dimensions and weight of the module?
A8: It measures 157 x 106 x 35 mm and weighs 0.47 kg.
