Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 8C-PDOD51 (Coated), 8U-PDOD51 (Uncoated) |
| IOTA Model | 8C-TDOD51 (Non-Redundant, Coated, 9″) / 8C-TDOD61 (Redundant, Coated, 12″) |
| Output Type | Current sinking (SINK) |
| Output Channels | 32 |
| Load Voltage | Max 30 VDC |
| Load Current | Max 0.1 A per channel |
| Short Circuit Protection | One fuse per 8 channels (total 4 fuses for 32 channels) |
| Galvanic Isolation | 1000 VAC RMS (System-to-Field, with user-supplied field power) |
| On-State Voltage | Max 1 VDC (at 0.1 A load current) |
| Off-State Voltage | Typically 24 VDC |
| Off-State Leakage Current | Max 100 µA |
| Turn-On / Turn-Off Time | Max 10 ms |
| Redundancy Output Switchover Gap | None (0 ms) |
| Dimensions | 60 x 155 x 145 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: How many output channels does the 8C-PDOD51 module support?
A1: It supports 32 digital output channels.
Q2: What type of output does this module provide?
A2: It provides current sinking (SINK) digital outputs.
Q3: Is the 8C-PDOD51 module short-circuit protected?
A3: Yes, each set of 8 channels is protected by a dedicated fuse, totaling 4 fuses for 32 channels.
Q4: Can this module operate in a redundant configuration?
A4: Yes, it supports redundant operation when paired with the appropriate IOTA (e.g., 8C-TDOD61).
Q5: What is the maximum load current per channel?
A5: The maximum load current per channel is 0.1 A.
Q6: What is the purpose of FAILOPT in this module?
A6: FAILOPT allows the output to either hold the last value or shed to a user-configurable safe value upon failure.
Q7: Is galvanic isolation provided?
A7: Yes, it provides 1000 VAC RMS galvanic isolation for system-to-field when using external field power.
Q8: What are the module’s physical dimensions and weight?
A8: The dimensions are 60 x 155 x 145 mm, and it weighs 0.3 kg.
