Technical Specifications
| Parameter | Specification |
|---|---|
| Module Name | 8C-SDOX01 Digital Output Relay Extension Module |
| Output Channels | 32 Isolated Form-C (SPDT) contacts, 3 screws per channel (NC, NO, COM) |
| Contact Type | Au over AgSnO₂ |
| Max Load Voltage | 250 VAC (RMS) / 125 VDC |
| Max Steady-State Load | 5A @ 125/250 VAC (resistive) 3A @ 30 VDC (resistive) 1A @ 48 VDC, etc. |
| Minimum Load Voltage | 5 VDC (if not previously used at high voltage/current) |
| Minimum Load Current | 10 mA or 100 mA (based on contact history) |
| Inrush Current (Max) | 10 A for 4 seconds at 10% duty cycle |
| Voltage Rating | 24 VDC |
| Module Current | 1010 mA |
| Isolation | 1500 VAC RMS or ±1500 VDC channel-to-channel and to logic common |
| Turn On/Off Time | Max 20 ms |
| Contact Life | Mechanical: ≥ 20,000,000 operations Electrical: ≥ 100,000 ops @ 3A resistive |
| Hot Swap Capability | Supported |
| Recommended Cable | Honeywell Part # 51155506-xxx (0.5m to 50m) |
| Dimensions (W×H×D) | 61 mm x 153 mm x 145 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of output does the 8C-SDOX01 support?
A1: It provides 32 Form-C (SPDT) isolated dry contacts, suitable for both NO and NC configurations.
Q2: What is the maximum current per output channel?
A2: Up to 5A at 125/250VAC (resistive) or 3A at 30VDC (resistive).
Q3: Does the module provide isolation between channels?
A3: Yes, 1500VAC RMS or ±1500VDC isolation is provided between channels and to logic common.
Q4: What is the minimum load requirement?
A4: 5VDC and 10mA if never used for high loads; otherwise 100mA is required.
Q5: Is hot-swapping supported?
A5: Yes, the module can be inserted or removed under power.
Q6: What is the operating voltage for the module?
A6: It operates at 24VDC.
Q7: What is the electrical contact life?
A7: At 3A resistive load, the relay contact life is ≥100,000 operations.
Q8: Is this module compatible with redundant configurations?
A8: Yes, it works with DO modules like 8C-PDODA1 and IOTAs for redundant output extension.
