Technical Specifications
| Parameter | Description |
|---|---|
| Module Name | 8C-TAID51 Digital Input Module |
| Manufacturer | Honeywell |
| Input Type | Digital Input |
| Number of Channels | 16 channels |
| Voltage Range | 18 VDC to 32 VDC |
| Typical Input Voltage | 24 VDC |
| Input Current | Up to 6 mA per channel |
| Input Filtering | Configurable (5 ms, 10 ms, 20 ms, etc.) |
| Isolation | Optically isolated from system logic |
| Redundancy Support | Supported |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 70°C |
| Dimensions | 61 x 153 x 145 mm |
| Weight | 0.3 kg |
| Mounting | Mounted on Series 8 IOTA baseboard |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many digital input channels does the 8C-TAID51 support?
A1: It supports 16 digital input channels.
Q2: What is the typical operating voltage of the 8C-TAID51?
A2: The typical input voltage is 24 VDC, with a supported range of 18 VDC to 32 VDC.
Q3: Does the module support redundancy?
A3: Yes, the 8C-TAID51 supports redundant configurations for improved system reliability.
Q4: Are the input channels electrically isolated?
A4: Yes, each input channel is optically isolated from the system logic.
Q5: What systems is this module compatible with?
A5: It is designed for use with Honeywell Experion PKS Series 8 system architecture.
Q6: Can the input filtering be configured?
A6: Yes, filtering can be set to values such as 5 ms, 10 ms, 20 ms, etc.
Q7: How is the module installed?
A7: It is installed on the Series 8 IOTA baseboard, which provides the electrical interface.
Q8: What is the operating temperature range of the module?
A8: The operating temperature range is 0°C to 60°C, suitable for industrial environments.
Tags
Packing & Delivery
We will use wear-resistant cartons to seal the boxes, and take photos for your confirmation before sealing. We will pack the boxes only after confirmation.
For express delivery, we will use DHL, UPS, TNT, FedEx and EMS.
Please rest assured that we have a deep cooperation with express delivery companies and can ensure that your goods are delivered to you in good condition.
