Technical Specifications
| Parameter | Description |
|---|---|
| Model | 8C-TDILB1 |
| Type | Digital Input IOTA (Redundant) |
| Input Channels | 32 channels digital input |
| Operating Voltage | 24 VDC |
| Voltage Range | 18–30 VDC |
| Module Current Draw | 95 mA |
| Input Signal Type | 24 VDC dry contact |
| ON Voltage/Current | ≥13 VDC or ≥3 mA |
| OFF Voltage/Current | ≤5 VDC or ≤1.2 mA |
| Input Impedance | 4.2 KΩ |
| Input Delay | 5 ms ± 20% |
| Isolation Method | Optical (inside IOM) |
| Isolation Voltage | 1000 VAC RMS or ±1500 VDC (System to Field) |
| Hot Swap Capability | Supported |
| Redundancy Support | Supported (requires dual modules + cable) |
| Dimensions | 200 × 130 × 90 mm |
| Weight | 1 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of module is the 8C-TDILB1?
A1: It is a redundant digital input I/O termination assembly in the Series 8 family, supporting 32 channels of 24VDC input.
Q2: Does it support redundant operation?
A2: Yes, it supports redundancy when used with paired IOMs and redundancy cabling.
Q3: Is hot swap supported for this module?
A3: Yes, the module is designed for hot insertion/removal while the system is powered.
Q4: What are the voltage and current thresholds for input signal detection?
A4: ON state requires ≥13VDC or ≥3mA; OFF state requires ≤5VDC or ≤1.2mA.
Q5: Does the module offer system-to-field electrical isolation?
A5: Yes, it provides 1000 VAC RMS or ±1500 VDC isolation via optical coupling.
Q6: What is the typical input delay per channel?
A6: The typical delay is 5 milliseconds with a ±20% margin.
Q7: What kind of application is this module intended for?
A7: It is ideal for industrial automation systems requiring reliable 24VDC digital input, including DCS and process control.
Q8: What are the physical dimensions and weight of the module?
A8: It measures 200 × 130 × 90 mm and weighs 1 kg.
