Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 8C-TDODA1 (Coated) |
| Number of Output Channels | 32 Channels |
| Output Type | Source |
| Rated Voltage | 24 VDC |
| Module Current Rating | 105 mA |
| Maximum Load Voltage | 30 VDC |
| Max Load Current/Channel | 100 mA (1 fuse per 8 channels, 4 fuses total) |
| Turn-On/Off Time | 10 ms (maximum) |
| On-State Voltage | 24 VDC typical (at max 0.1A load current) |
| Off-State Voltage | 0 VDC |
| Off-State Leakage Current | 5 μA (maximum) |
| Isolation | 1000 VAC RMS (System-to-Field, with external power) |
| Hot Swap Capability | Supported |
| Operating Temperature | 0 to 60 ℃ |
| Storage Temperature | -40 to 85 ℃ |
| Safety Certification | Class I, Div 2, Groups A-D, T4; Zone 2, Ex nA II C T4 |
| Dimensions | 152 x 50 x 118 mm |
| Weight | 0.35 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the output type of the 8C-TDODA1?
A1: It is a Source-type digital output used to provide positive voltage control.
Q2: Does the module support redundancy?
A2: No, the 8C-TDODA1 is a non-redundant version. For redundancy, use 8C-TDODB1.
Q3: What is the maximum current per channel?
A3: Each channel supports up to 100 mA. Fuse protection is used for overcurrent.
Q4: Is the module hot-swappable?
A4: Yes, the module can be removed or inserted under power.
Q5: Is isolation provided when using system power?
A5: No. System-to-field isolation is only available when using external field power.
Q6: Does the module have short-circuit protection?
A6: Yes, one fuse is installed for every 8 channels to protect against short circuits.
Q7: What is the supported load voltage range?
A7: The module supports a load voltage of up to 30 VDC.
Q8: What is the standard operating temperature range?
A8: The operating range is 0 to 60℃, and the storage range is -40 to 85℃.
