Technical Specifications
| Parameter | Description |
|---|---|
| Model | CC-GAIC21 |
| Input Type | Voltage, current (2-wire or self-powered transmitters) |
| Input Channels | 16 Channels (12 single-ended, 4 differential) |
| Input Signal Range | 0–5V, 1–5V, 0.4–2V, 4–20mA (via 250Ω resistor) |
| Common Mode Rejection | 70 dB (DC to 60Hz, 500Ω imbalance) |
| Common Mode Voltage | -6V to +5V peak |
| ADC Resolution | 16-bit |
| Normal Mode Rejection | 19 dB at 60 Hz |
| Input Impedance | >10 MΩ (voltage input) |
| Max Normal Mode Input | ±30V (differential input, non-damaging) |
| Crosstalk | -60 dB channel-to-channel |
| Input Scan Rate | 50 milliseconds |
| Hardware Accuracy | ±0.075% at 23.5°C ± 2°C; ±0.15% from 0 to 60°C |
| Field Power Protection | Individually current-limited per channel, Class 1 Div 2 |
| Dimensions (mm) | 63.5 x 124.46 x 307.34 |
| Weight | 0.32 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What sensor types are supported by the CC-GAIC21?
A1: It supports voltage and current input sensors, including 2-wire and self-powered transmitters.
Q2: Does it support differential inputs?
A2: Yes, it supports 4 differential input channels, the rest are single-ended.
Q3: What is the analog input accuracy?
A3: ±0.075% at 23.5°C and ±0.15% from 0 to 60°C full-scale.
Q4: What input signal ranges are accepted?
A4: 0–5V, 1–5V, 0.4–2V, and 4–20mA (through 250Ω resistor).
Q5: Is HART protocol supported?
A5: No, the CC-GAIC21 does not support HART. Use a HART-enabled module for that feature.
Q6: What is the scan rate of each channel?
A6: The input scan rate is 50 milliseconds per channel.
Q7: Is it suitable for intrinsically safe applications?
A7: Yes, it features current-limited protection per channel for Class 1, Div 2 non-incendive zones.
Q8: Are there wiring requirements during installation?
A8: Use up to 2.5 mm² stranded wire, and configure the IOTA jumpers according to the input type.
