Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | CC-PAIH02 |
| Description | High-Level Analog Input Module with HART, 16 Channels |
| Input Type | Analog current input (4–20 mA), HART communication supported |
| Number of Channels | 16 |
| Input Range | 4–20 mA |
| Input Type Support | Single-ended and differential (all 16 channels support differential) |
| IOTA Compatibility | CC-TAIX01, CC-TAIX11, CC-GAIX11, CC-GAIX21, CC-TAID01, CC-TAID11 |
| Redundancy | Supported |
| Signal Isolation | Channel-to-channel isolation via IOTA (dependent on IOTA type) |
| Power Supply | Supplied through IOTA |
| HART Protocol Support | Yes |
| Ambient Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | 0.2g @ 0–60Hz |
| Shock Resistance | 5g for 30ms |
| Pollution Degree | 2 |
| Overvoltage Category | II |
| Dimensions (W x H x D) | 159 mm x 50 mm x 160 mm |
| Weight | 0.8 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many channels does the CC-PAIH02 support?
A1: The module supports 16 high-level analog input channels with full HART capability.
Q2: Are all channels on the CC-PAIH02 capable of differential input?
A2: Yes, all 16 channels support differential input.
Q3: Does the CC-PAIH02 module support HART communication?
A3: Yes, it fully supports HART communication on all channels.
Q4: Can the CC-PAIH02 be used in redundant configurations?
A4: Yes, the module supports redundant configurations when used with appropriate IOTAs.
Q5: What type of IOTAs is the CC-PAIH02 compatible with?
A5: It is compatible with CC-TAIX01, CC-TAIX11, CC-GAIX11, CC-GAIX21, CC-TAID01, and CC-TAID11.
Q6: What is the input signal range for the CC-PAIH02?
A6: The module accepts 4–20 mA analog current input.
Q7: What environmental conditions does the CC-PAIH02 operate under?
A7: It operates between 0°C and +60°C with 5–95% non-condensing humidity.
Q8: Is the CC-PAIH02 suitable for use in galvanically isolated/intrinsically safe environments?
A8: Yes, when used with the correct GI/IS IOTAs such as CC-GAIX11 and CC-GAIX21.
