Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | CC-PDIS01 |
| Function | 24VDC Digital Input, supports Sequence of Events (SOE) |
| Input Channels | 32 |
| Input Scan Modes | Normal: 20 ms, Fast: 5 ms, SOE: 1 ms resolution |
| Digital Input Resolution (SOE) | 1 ms |
| Input Voltage Range | 18 – 30 VDC |
| ON Sense Threshold | ≥ 13 VDC or ≥ 3 mA |
| OFF Sense Threshold | ≤ 5 VDC or ≤ 1.2 mA |
| Input Impedance | 4.2 kΩ |
| Galvanic Isolation | 1500 VAC RMS or ±1500 VDC |
| Isolation Type | Optical |
| Absolute Delay | 5 ms ± 20% |
| Open Wire Detection | Yes (only in Normal mode) |
| Redundancy Support | Yes |
| Mounting IOTA Options | CC-TDIL01 (9″), CC-TDIL11 (12″), CC-GDIL11 (12″), CC-GDIL21 (6″), others |
| Dimensions (W x H x D) | 63.5 mm x 124.46 mm x 307.34 mm |
| Weight | 0.231 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the input voltage range for the CC-PDIS01?
A1: The module operates with 18 to 30 VDC input signals.
Q2: How many digital inputs does the CC-PDIS01 support?
A2: It supports 32 digital input channels.
Q3: Does CC-PDIS01 support Sequence of Events (SOE) logging?
A3: Yes, it supports 1 ms resolution SOE for time-stamped input changes.
Q4: Is the CC-PDIS01 module redundant capable?
A4: Yes, redundancy is supported via compatible IOTAs like CC-TDIL11.
Q5: What isolation method is used in this module?
A5: Optical isolation is employed to separate input channels from logic circuitry.
Q6: Does the CC-PDIS01 provide open wire detection?
A6: Yes, open wire detection is available in normal mode.
Q7: What is the scan time in fast mode?
A7: The fast scan mode provides a 5 ms PV scan rate.
Q8: What are the dimensions and weight of the module?
A8: The module dimensions are 63.5 x 124.46 x 307.34 mm, and it weighs 0.231 kg.
