Technical Specifications
| Parameter | Description |
|---|---|
| Model | FS-TIDI-1624 |
| Type | Digital Input Field Termination Assembly |
| Number of Channels | 16 Digital Inputs |
| Input Signal Type | 24 VDC Discrete Input |
| Connector Type | Removable Terminal Blocks |
| Power Supply | Supplied via system backplane |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Isolation Voltage | 1500 V RMS |
| Dimensions (W×H×D) | 265 × 70 × 48 mm |
| Weight | 0.45 kg |
| Mounting | Standard I/O rack |
| Application | Safety system digital signal termination |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of input signals does the FS-TIDI-1624 support?
A1: It supports 24 VDC discrete (digital) input signals.
Q2: How many input channels are available on the FS-TIDI-1624?
A2: The module provides 16 digital input channels.
Q3: What is the isolation rating for this module?
A3: It has an isolation voltage rating of 1500 V RMS.
Q4: What are the operating temperature limits for the FS-TIDI-1624?
A4: The operating temperature range is from 0°C to 60°C.
Q5: How is the module powered?
A5: The FS-TIDI-1624 is powered via the system backplane.
Q6: Can this module be hot-swapped during operation?
A6: No, hot-swapping is not supported. Power down the system before replacement.
Q7: What is the size and weight of the FS-TIDI-1624?
A7: The module measures 265 × 70 × 48 mm and weighs 0.45 kg.
Q8: What is the mounting method used for FS-TIDI-1624?
A8: It mounts on a standard I/O rack as part of the safety system.
