Technical Specifications
| Parameter | Description |
|---|---|
| Model | MC-PAOY22 |
| Part Number | 80363949-150 |
| Module Type | Analog Output Module |
| Output Channels | 8 channels |
| Output Signal | 4–20 mA analog signal |
| Output Accuracy | ±0.05% of full scale |
| Power Supply | 24 VDC (supplied from system bus) |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Redundancy | Supported |
| Operating Temp. | 0°C to 60°C |
| Storage Temp. | -40°C to 85°C |
| Mounting Method | Plug-in module on I/O backplane |
| Dimensions (WxHxD) | 126 × 28 × 130 mm |
| Weight | 0.21 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of module is MC-PAOY22?
A1: It is an 8-channel analog output module designed for 4–20 mA current signal outputs.
Q2: Does MC-PAOY22 provide channel isolation?
A2: Yes, the module provides channel-to-channel and channel-to-system isolation to ensure signal integrity and system safety.
Q3: Which systems is this module compatible with?
A3: It is primarily used in Honeywell TPS and Experion control systems.
Q4: Is redundancy supported by MC-PAOY22?
A4: Yes, redundancy is supported for high-reliability configurations.
Q5: What is the output accuracy of this module?
A5: The output accuracy is ±0.05% of full scale.
Q6: How is the module installed?
A6: It is installed by plugging into the I/O backplane and supports hot swapping.
Q7: What are the environmental requirements?
A7: Operating temperature is 0°C to 60°C; storage temperature is -40°C to 85°C.
Q8: What are the module’s dimensions and weight?
A8: The dimensions are 126 × 28 × 130 mm, and the weight is 0.21 kg.
