Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | MC-PDOX02 |
| Part Number | 51304487-150 |
| Product Type | Digital Output Processor Module |
| Channel Type | Digital Output |
| Installation | Card-mounted, compatible with HPM card slot |
| Communication | I/O Link communication to IOP |
| Redundancy | Supported (depending on IOP configuration) |
| Operating Voltage | 24 VDC standard |
| Housing | Industrial-grade metal enclosure |
| Dimensions | 214 x 30 x 119 mm |
| Weight | 0.28 kg |
| Operating Env. | Industrial automation systems, supports remote I/O setups |
| Compatible System | Honeywell High-Performance Process Manager (HPM) |
| Mounting | Central or Remote IOP Rack |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the MC-PDOX02 module?
A1: It processes digital output signals from the controller and transfers them to field-connected output devices.
Q2: Does it support redundancy?
A2: Yes, it supports redundancy when paired with a secondary IOP module.
Q3: How many digital output channels does it support?
A3: The number of output channels depends on the connected Field Termination Assembly (FTA), not the module itself.
Q4: Can this module be installed in remote I/O racks?
A4: Yes, with the use of an I/O Link Extender, it can be located remotely from the main control cabinet.
Q5: What precautions should be taken during installation?
A5: Ensure correct insertion into the IOP slot and proper cable connections to the FTA to avoid electrical noise.
Q6: Is hot-swapping supported?
A6: No, power must be turned off before replacing the module.
Q7: Which systems are compatible with this module?
A7: It is compatible with Honeywell’s TPS systems utilizing the High-Performance Process Manager architecture.
Q8: What is the recommended maintenance cycle?
A8: Routine inspection and functional testing are recommended every 2 to 3 years under normal operating conditions.
