Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Digital Output Module (DO) |
| Output Channels | 16 Channels |
| Output Type | 24 VDC, Solid-State |
| Isolation | Galvanically isolated channels |
| Voltage Range | 18 – 30 VDC |
| Max Load Current | 0.5 A per channel |
| Protection | Short-circuit and overvoltage protection |
| Field Power Supply | External 24 VDC |
| Diagnostics | Channel status and fault indication |
| Mounting | Installed in IOP card file |
| Cooling Method | Convection cooling |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 70 °C |
| Dimensions (W x H x D) | 28 x 318 x 278 mm |
| Weight | 0.58 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the MC-PDOY22 module support redundant configuration?
A1: Yes, the MC-PDOY22 can be used in a redundant setup with a secondary module of the same type.
Q2: What is the maximum load current per output channel?
A2: Each output channel supports a maximum current of 0.5 A.
Q3: Is short-circuit protection included in this module?
A3: Yes, the module includes built-in short-circuit and overvoltage protection.
Q4: What is the operating temperature range of the MC-PDOY22?
A4: The module operates within a temperature range of 0 to 60°C.
Q5: Is an external power supply required?
A5: Yes, the module requires an external 24 VDC power source.
Q6: How is channel status diagnosed?
A6: Each channel features individual status and fault LEDs for local diagnostics.
Q7: What is the mounting method for this module?
A7: The module is installed into an IOP card file via slot insertion.
Q8: How is electrical isolation achieved?
A8: Each channel is galvanically isolated to ensure system safety and signal integrity.
