Technical Specifications
| Parameter | Description |
|---|---|
| Number of Input Channels | 32 channels |
| Input Voltage Range | 20-30 VDC |
| Rated Input Voltage | 24 VDC |
| Sense Current (ON) | ≥4.5 mA |
| Sense Current (OFF) | ≤2.8 mA |
| Pick Up Voltage (ON) | ≥20 VDC |
| Drop Out Voltage (OFF) | ≤10 VDC |
| Input Frequency Range | DC |
| Optical Isolation | 1500 VAC rms or ±1500 VDC |
| Isolation Technique | Optical isolation |
| Input Delay | Max. 2.0 ms |
| Accumulated Input Frequency | DC – 15 Hz |
| Dimensions | 462.3 x 120.7 mm |
| Weight | 0.68 kg |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 10%～90%, non-condensing |
| Surge Withstand Capability | ANSI/IEEE C37.90.1-1978 |
FAQ
FAQ (Frequently Asked Questions)
Q1: How many digital input channels are supported?
A1: The module supports 32 digital input channels.
Q2: What is the rated input voltage of this module?
A2: The rated input voltage is 24 VDC, and the operating range is 20-30 VDC.
Q3: What is the optical isolation level for each input?
A3: Each channel is optically isolated to 1500 VAC rms or ±1500 VDC.
Q4: What is the typical input delay for the module?
A4: The maximum input delay is 2.0 ms.
Q5: What are the dimensions and weight of the module?
A5: The module measures 462.3 x 120.7 mm and weighs 0.68 kg.
Q6: What are the sense current values for ON and OFF states?
A6: Sense current is at least 4.5 mA (ON), and not more than 2.8 mA (OFF).
Q7: What are the typical application scenarios for this module?
A7: It is typically used for digital signal acquisition in industrial automation, such as monitoring switch signals.
Q8: What are the environmental conditions for operation?
A8: Operating temperature is 0°C to 50°C, with relative humidity of 10%–90% (non-condensing).
