Technical Specifications
| Parameter | Description |
|---|---|
| Model | MU-TDOY23 51204166-125 |
| Output Points | 32 digital outputs |
| Output Type | Relay output |
| Operating Voltage | 24 VDC / 120 VAC / 240 VAC (according to config) |
| Rated Output Current | 2A per point |
| Isolation | Opto-isolated channels |
| Mounting | DIN rail mounting |
| Terminal Type | Screw-clamp terminals |
| Operating Temperature | 0~50°C |
| Storage Temperature | -40~70°C |
| Humidity Range | 10%~90% (non-condensing) |
| Dimensions (WxHxD) | 304.8 x 81.3 x 12.7 mm |
| Weight | 0.18 kg |
| Controller Compatibility | PM/APM/HPM Controllers |
| Typical Applications | Process automation, industrial control systems |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which control systems are compatible with the MU-TDOY23?
A1: This module is compatible with Honeywell PM, APM, and HPM control systems, suitable for various process automation platforms.
Q2: What is the rated output current per channel?
A2: The rated output current per channel is 2A.
Q3: Does the module provide opto-isolation?
A3: Yes, all output channels feature opto-isolation for enhanced system safety.
Q4: What voltage types does MU-TDOY23 support?
A4: Supports 24VDC, 120VAC, and 240VAC voltage types; selectable per application.
Q5: What is the mounting method?
A5: DIN rail mounting, suitable for integration in standard industrial control cabinets.
Q6: What is the operating temperature range?
A6: The operating temperature range is 050°C; storage temperature is -4070°C.
Q7: What are the typical applications for this module?
A7: Common applications include process automation, production equipment control, industrial alarm and actuator driving.
Q8: What is the terminal wiring method?
A8: Uses screw-clamp terminals for convenient and secure field wiring.
