Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 1B30023H02 |
| Product Type | I/O Bus Terminator Module |
| Application | Emerson OVATION Control System |
| Mounting Type | DIN rail mounting |
| Interface Type | Bus termination interface |
| Operating Temp. | 0°C to 60°C |
| Storage Temp. | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Electrical Isolation | Yes (isolated from system bus) |
| Enclosure Material | Industrial-grade flame-retardant plastic |
| Dimensions | 100 × 50 × 25 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of this module?
A1: The 1B30023H02 module functions as a terminator for the OVATION system’s I/O bus to prevent signal reflection and communication faults.
Q2: Does this module require a separate power supply?
A2: No, it is powered through the system bus connection and does not need an external power source.
Q3: Which OVATION modules is it compatible with?
A3: It is compatible with OVATION I/O modules, controllers, and communication modules as a physical bus terminator.
Q4: Does the installation position affect its functionality?
A4: Yes, it must be installed at the end of the I/O bus to ensure stable communication.
Q5: Is the module hot-swappable?
A5: No, for system stability, the module should be replaced with the power turned off.
Q6: Does this module require regular maintenance?
A6: No routine maintenance is required, though periodic inspection of connections and casing is recommended.
Q7: Does the module include status indicator LEDs?
A7: No, it does not include any LEDs; the design is kept simple for termination purposes only.
Q8: Is the enclosure rated for protection (IP rating)?
A8: It is made from industrial plastic but is not IP-rated; it should be installed in a protected control cabinet environment.
