Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Sequence of Events (SOE) Contact Input |
| Input Channels | 32 contact input channels |
| Input Voltage Range | 24 VDC (nominal) |
| Input Type | Dry contact (non-powered) |
| Input Filtering | Software-configurable debounce filter |
| Timestamp Resolution | 1 millisecond |
| Isolation | Channel-to-logic and channel-to-channel |
| Diagnostics | Channel status and fault diagnostics |
| Power Supply Requirement | Supplied by I/O chassis backplane |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (W x H x D) | 121 x 54 x 140 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 1C31157G03 module?
A1: It captures and time-stamps contact input changes for sequence-of-events recording.
Q2: How many input channels does this module support?
A2: The module supports 32 dry contact input channels.
Q3: What kind of input signals are accepted by this module?
A3: It accepts dry contact signals typically associated with digital field devices.
Q4: What is the timestamp resolution of the SOE events?
A4: The module provides 1 millisecond timestamp resolution for accurate event logging.
Q5: Does the module offer input signal isolation?
A5: Yes, the channels are isolated both from logic and from each other.
Q6: Can input debounce filtering be configured?
A6: Yes, the debounce filter settings are software-configurable to reduce false events.
Q7: What type of diagnostics are available?
A7: The module provides per-channel diagnostics including input state and fault detection.
Q8: Is external power required for the input signals?
A8: No, the module is designed for dry contacts and does not require external power for inputs.
