Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product Type | Intrinsically safe analog output module |
| Software Compatibility | Unity Pro / Concept V2.2 and above / ProWORX |
| Number of Analog Outputs | 8 |
| Output Range | 0…20 mA (0–20000 points) |
| 0…25 mA (0–25000 points) | |
| 4…20 mA, 15 bits (0–16000 points) | |
| 4…20 mA, 15 bits (0–4095 points) | |
| Max Loop Resistance | 500 Ohm |
| Absolute Accuracy Error | ±0.2% of full scale @ 25°C (77°F) |
| Accuracy Drift (Temperature) | ≤70 ppm/°C / 40 ppm/°C |
| Linearity | ±1 LSB |
| Update Time | 4 ms |
| Setting Time | 1 ms to ±0.1% of the final value |
| Isolation (Channel to Bus) | 1780 Vrms for 60 seconds (AC) |
| Fault Type Detection | Open circuit detection for 4…20 mA outputs |
| Power Dissipation | 12.5 W |
| Hot Swapping | Not permitted (per intrinsic safety standards) |
| Protection Type | Internal fuse |
| Certification Marking | CE, II1 G/D-EEx ia IIC |
| Bus Current Requirement | 2.5 A |
| Module Format | Standard |
| Dimensions (W x H x D) | 50 x 165 x 310 mm |
| Weight | 0.8 kg (0.7 lb) |
| Protective Coating | Conformal coating (Humiseal 1A33) |
| Standards Compliance | UL 508, EN 50014, EN 50020, EN 50281-1-1, CSA C22.2 No.142, etc. |
| ATEX Directive | 94/9/EC |
| Certifications | FM Class 1 Div 2, SIRA 02ATEX2345X, C-Tick |
| ESD Resistance | 4 kV (contact), 8 kV (air) IEC 801-2 |
| EMI Resistance | 9.1 V/m (10 V/m), 80–2000 MHz IEC 801-3 |
| Operating Temperature | 0…60°C (32…140°F) |
| Storage Temperature | -40…85°C (-40…185°F) |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤5000 m (16404.2 ft) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 140AIO33000C module?
A1: It is designed to provide intrinsically safe analog current outputs for use in hazardous areas requiring Zone 20, 21, or 22 compliance.
Q2: Can this module be hot-swapped while powered?
A2: No, hot swapping is not permitted due to intrinsic safety restrictions.
Q3: What analog output ranges are supported?
A3: The module supports 0–20 mA, 0–25 mA, and 4–20 mA across multiple resolution levels.
Q4: What is the maximum loop resistance the module can handle?
A4: The module supports up to 500 Ohms of loop resistance.
Q5: Is this module compliant with ATEX standards?
A5: Yes, it complies with Directive ATEX 94/9/EC and carries appropriate ATEX markings.
Q6: What type of fault does the module detect?
A6: It can detect open circuit faults specifically on 4–20 mA output channels.
Q7: What protective coating is applied to this module?
A7: The module uses a conformal coating, Humiseal 1A33, for environmental protection.
Q8: What certifications does the module have for hazardous locations?
A8: It is certified for FM Class 1 Division 2, SIRA 02ATEX2345X, and C-Tick approval.
