Technical Specifications
| Parameter | Value |
|---|---|
| Range of Product | Modicon Quantum Automation Platform |
| Product Type | DC Discrete Input Module |
| Number of Inputs | 24 channels |
| Group of Channels | 3 groups |
| Logic Input Type | Positive (sinking) |
| Input Voltage Range | 88 to 150 V DC |
| Nominal Input Voltage | 125 V DC @ 2.5 mA |
| Maximum Input Voltage | 156.25 V DC including ripple |
| Response Time (0→1 / 1→0) | 0.7 ms |
| Addressing Requirement | 2 input words |
| Module Format | Standard |
| Group-to-Bus Isolation | 2500 Vrms for 1 minute |
| Group-to-Group Isolation | 700 Vrms for 1 minute |
| Power Dissipation | 1 W + (0.62 × number of active inputs) |
| Bus Current Requirement | 200 mA |
| Local Signaling | 1 green LED for bus active 1 red LED for external fault 24 green LEDs for input status |
| Marking | CE, UL 508, CSA C22.2 No 142 |
| Product Certifications | C-Tick, FM Class 1 Division 2 |
| ESD Resistance | 4 kV contact, 8 kV air (IEC 801-2) |
| EMI Resistance | 9.1 V/m (10 V/m) from 80 to 2000 MHz (IEC 801-3) |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 95% non-condensing |
| Maximum Operating Altitude | ≤ 5000 m (16404.2 ft) |
| Dimensions (H × W × D) | 103.9 × 40.3 × 250 mm |
| Net Weight | 0.3 kg (0.7 lb) |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the 140DDI67300 support isolated input groups?
A1: Yes, the module has 3 input groups with 700 Vrms isolation between groups.
Q2: Can this module handle high-voltage DC inputs?
A2: Yes, it supports DC input from 88 to 150 V and withstands up to 156.25 V including ripple.
Q3: What is the current draw per input point?
A3: Each input point draws approximately 2.5 mA at 125 V DC.
Q4: Does the module display input status locally?
A4: Yes, 24 green LEDs indicate the real-time status of all input points.
Q5: How much address space does it consume?
A5: The module requires 2 input words.
Q6: Is the module suitable for harsh industrial environments?
A6: Yes, it complies with IEC 801 standards for ESD and EMI protection.
Q7: What certifications does it carry?
A7: It is certified for CE, UL, CSA, C-Tick, and FM Class 1 Division 2 applications.
Q8: Is there an indicator for external faults?
A8: Yes, a red LED (F) indicates any external fault conditions.
