Technical Specifications
| Parameter Category | Description |
|---|---|
| Product Range | Modicon Quantum Automation Platform |
| Product Type | Ethernet Control Module |
| Compatible Products | 140CPU6xxxx |
| Communication Protocol | Modbus TCP, EtherNet/IP |
| Exchange Mode | Full Duplex |
| Max Number of Connections | 64 |
| Transmission Rate | 10/100 Mbit/s |
| Redundancy Support | Yes, Hot Standby Redundant Architecture |
| Network Topology | Daisy Chain Loop, Redundant Ring |
| Embedded Web Server | Yes |
| Communication Services | NTP Time Sync, FDR Server, CIP Messaging (Explicit & Implicit), Embedded Router, SNMP Agent, QoS, SMTP Notification, DHCP/BootP Server, DTM, RSTP |
| Ethernet Ports | RJ45 10BASE-T/100BASE-TX, Embedded 4-port Switch |
| Transmission Medium | Twisted Pair |
| Power Supply | Powered via rack power supply |
| Local Signaling LEDs | Active (Green), Ready (Green), Mod Status (Green/Red), Net Status (Green/Red), Net Status 1 (Green/Red), Net Status 2 (Green/Red) |
| Module Format | Standard |
| Product Certifications | CE, UL, FM Class 1 Div 2, CSA, GOST, C-Tick, LR, Marine Certification |
| IP Protection Rating | IP20 |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Relative Humidity | 10–95% at 60 °C, non-condensing |
| Dimensions (W × D × H) | 103.9 × 40.3 × 250 mm |
| Weight | 0.345 kg (0.761 lb) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What communication protocols does the 140NOC78100 module support?
A1: It supports both Modbus TCP and EtherNet/IP protocols.
Q2: Does this module support redundancy?
A2: Yes, it supports hot standby redundancy for high availability systems.
Q3: How many Ethernet connections can this module handle?
A3: It can handle up to 64 simultaneous connections.
Q4: Is a web server integrated into the module?
A4: Yes, an embedded web server is included for remote access and diagnostics.
Q5: How is the module powered?
A5: The module is powered via the Quantum rack’s power supply.
Q6: Does the module support time synchronization?
A6: Yes, it supports NTP for network time synchronization.
Q7: What network management features are available?
A7: The module includes QoS, SMTP alerts, DHCP/BootP, SNMP Agent, and more.
Q8: Is there a built-in Ethernet switch?
A8: Yes, a 4-port Ethernet switch is embedded to support daisy chain or ring topology.
