Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product Type | DIO Head-End Adaptor |
| Product Compatibility | 140CRA21120, 140CRA21110 |
| Number of Ports | 1 × Modbus Plus RS485 (twisted pair, single copper) |
| 1 × Modbus RS232 (twisted pair, single copper) | |
| Transmission Rate | 1 Mbit/s |
| I/O Capacity | 30 Input words / 32 Output words |
| Internal Checks | Processor, Checksum, RAM Address, RAM Integrity |
| Power Dissipation | 4 W |
| Bus Current Requirement | 780 mA |
| Module Format | Standard |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.482 kg |
| ESD Resistance | 4 kV contact (IEC 801-2), 8 kV air (IEC 801-2) |
| Electromagnetic Field Resistance | 9.1 V/m (10 V/m) from 80 to 2000 MHz (IEC 801-3) |
| Operating Temperature | 32 to 140 °F (0 to 60 °C) |
| Storage Temperature | -40 to 185 °F (-40 to 85 °C) |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m (16404.2 ft) |
| Standards | UL 508 |
| Product Certifications | CSA, RMRS, FM Class 1 Division 2, C-Tick, GOST |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 140NOM21100 module?
A1: It serves as a head-end adaptor for distributed I/O systems in the Modicon Quantum platform.
Q2: How many communication ports are provided?
A2: It provides two ports: one Modbus Plus RS485 and one Modbus RS232.
Q3: Is it compatible with other Quantum modules?
A3: Yes, it is compatible with 140CRA21120 and 140CRA21110 modules.
Q4: What is the transmission speed supported?
A4: The module supports a transmission rate of 1 Mbit/s.
Q5: How many I/O words are handled by the module?
A5: It handles 30 input words and 32 output words.
Q6: What are the environmental limits for operation?
A6: The operating temperature range is 0 to 60 °C, with up to 95% non-condensing humidity.
Q7: What standards and certifications does the module meet?
A7: It complies with UL 508 and is certified by CSA, RMRS, FM (Class 1 Div 2), C-Tick, and GOST.
Q8: What is the physical size and weight of the unit?
A8: The unit measures 103.9 × 40.3 × 250 mm and weighs 0.482 kg.
