Technical Specifications
| Parameter | Value |
|---|---|
| Product Range | Modicon Momentum Automation Platform |
| Product Type | Fipio Communication Adaptor |
| Platform Compatibility | Momentum I/O Base |
| Bus Manager | Premium |
| Communication Protocol | Fipio |
| Access Method | Producer/Consumer Principle |
| Transmission Rate | 1 Mbit/s |
| Transmission Medium | Optical Fibre 50/125 Optical Fibre 62.5/125 Twisted Shielded Pairs |
| Topology | Extension or Tap-Off Cable |
| Devices per Segment | 0–31 without repeater Up to 97 with repeater |
| Max Cable Distance | 5000 m (16404.2 ft) |
| Fail State Behavior | Maintain value / Zero / Full-scale value / Force to zero |
| Power Supply | Supplied from I/O base |
| Local Indicators | RUN (Green), ERR (Red), COM (Yellow) LEDs |
| Protection Rating | IP20 (Open Industrial Support Conforming to Fip Standard) |
| Dimensions (W × H × D) | 53 × 177 × 258 mm |
| Weight | 0.11 kg (0.24 lb) |
| Electrostatic Discharge | 4 kV contact / 8 kV air (IEC 801-2) |
| EMC Immunity | 9.1 V/m (10 V/m), 80…1000 MHz (IEC 801-3) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 95% non-condensing |
| Operating Altitude | ≤ 5000 m (16404.2 ft) |
| Protective Treatment | TC |
| Certifications | CE, UL, CSA |
FAQ
Frequently Asked Questions (FAQ)
Q1: What communication protocol does the 170FNT11001 adaptor support?
A1: It supports the Fipio protocol using a producer/consumer communication model.
Q2: What types of cables can be used with this module?
A2: It supports optical fibre 50/125, 62.5/125, and twisted shielded pair cables.
Q3: How many devices can connect on a segment with this adaptor?
A3: Up to 31 devices without a repeater, and up to 97 with a repeater.
Q4: How is the adaptor powered? Does it need external power?
A4: No external power is needed; it is powered directly from the I/O base.
Q5: Does the 170FNT11001 have fail-safe handling?
A5: Yes, it supports fail behaviors like maintain value, zero output, or full-scale output.
Q6: What status indicators are present on the module?
A6: There are three LED indicators: green for RUN, red for ERR, and yellow for COM.
Q7: What is the protection and immunity level of this adaptor?
A7: It has IP20 protection and complies with IEC 801-2 and 801-3 EMC standards.
Q8: What is the operating temperature range of this device?
A8: It operates within 0 to 60 °C, suitable for typical industrial environments.
