Product Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Premium Automation Platform |
| Product Type | Unity Processor |
| Software Compatibility | Unity Pro |
| Rack Compatibility | 2 racks (12 slots each), 4 racks (4/6/8 slots) |
| Number of Slots | 16, 24, or 32 |
| Discrete I/O Processor Capacity | 512 I/O points |
| Analog I/O Processor Capacity | 24 I/O points |
| Application-Specific Channels | 8 |
| Integrated Connection Type | Non-isolated serial link (2 female mini DIN RS485, 19.2 kbit/s) |
| Communication Module Processor Capacity | 2 or 1 modules |
| Internal Memory (without PCMCIA card) | 96 kB program and data |
| Internal Memory (with PCMCIA card) | 224 kB program, 96 kB data |
| PCMCIA Card Support | 256 kB additional data storage |
| Max Object Area – Unlocated Data | 32 kB (elementary and derived data) |
| Max Object Area – Located Bits | 4096 %Mi |
| Max Object Area – Constant Words | 64 %KWi |
| Max Object Area – Internal Words | 64 %MWi |
| Max Object Area – Function Blocks (DFB/EFB) | 64 kB unlocated internal data |
| Application Structure | 32 event tasks, 1 master task, 1 fast task |
| Execution Time (Boolean, no card) | 0.19 µs |
| Execution Time (Boolean, with card) | 0.25 µs |
| Execution Time (Word/Fixed Arithmetic, no card) | 0.25 µs |
| Execution Time (Word/Fixed Arithmetic, with card) | 0.5 µs |
| Execution Time (Floating Point) | 1.75…2.6 µs (with or without PCMCIA card) |
| Instruction Throughput | 2.1 Kinst/ms (65% Boolean + 35% arithmetic, with card) |
| 3.1 Kinst/ms (100% Boolean, with card) | |
| 3.71 Kinst/ms (65% Boolean + 35% arithmetic, no card) | |
| 4.76 Kinst/ms (100% Boolean, no card) | |
| System Overhead Time | 0.3 ms (fast task), 1 ms (master task) |
| Marking | CE |
| Local Signaling | RUN (green), I/O fault (red), ERR (red), TER activity (yellow) LEDs |
| Current Consumption | 850 mA at 5 V DC |
| Module Format | Standard |
| Net Weight | 0.38 kg (0.84 lb US) |
| Package Dimensions | 55 mm x 180 mm x 260 mm |
| Standards Compliance | UL 508, CSA C22.2 No 142, IEC 61131-2, 73/23/EEC, 89/336/EEC, 92/31/EEC, 93/68/EEC |
| Certifications | RMRS, GL, LR, ABS, BV, DNV, RINA |
| Ambient Operating Temperature | 0…60 °C (32…140 °F) |
| Ambient Storage Temperature | -25…70 °C (-13…158 °F) |
| Relative Humidity (Operation) | 10…95% non-condensing |
| Relative Humidity (Storage) | 5…95% non-condensing |
| Operating Altitude | 0…2000 m (0…6561.68 ft) |
| Protective Treatment | TC |
| IP Degree of Protection | IP20 |
| Pollution Degree | 2 |
FAQ
Frequently Asked Questions (FAQs)
Q1: What is the maximum number of I/O modules supported by the TSXP57104M processor?
A1: The processor supports up to 512 discrete I/O points and 24 analog I/O points.
Q2: Does the TSXP57104M support PCMCIA memory expansion?
A2: Yes, it supports a PCMCIA card with up to 256 kB additional data storage.
Q3: What communication interface is integrated in this processor?
A3: It includes a non-isolated serial link with 2 female mini DIN RS485 connectors operating at 19.2 kbit/s.
Q4: What is the total memory available without using a PCMCIA card?
A4: Without a PCMCIA card, the processor provides 96 kB of combined program and data memory.
Q5: How does the execution speed vary with and without a PCMCIA card?
A5: Boolean instructions execute at 0.19 µs without a card and 0.25 µs with a card. Floating-point instructions take 1.75 to 2.6 µs in both cases.
Q6: What are the operating temperature limits of the TSXP57104M?
A6: The processor operates reliably within a temperature range of 0°C to 60°C (32°F to 140°F).
Q7: What type of local LED indicators are available on the unit?
A7: The unit provides LEDs for processor run (green), I/O or configuration fault (red), system fault (red), and terminal activity (yellow).
Q8: What certifications does the TSXP57104M comply with for marine and industrial applications?
A8: It holds certifications from ABS, BV, DNV, GL, LR, RINA, and RMRS, suitable for demanding industrial and marine environments.
