Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Premium Automation Platform |
| Product or Component Type | Bus X Remote Rackmaster Module |
| Number of Channels | 2 |
| Method of Access | Master/Slave |
| Electrical Connection | 1 SUB-D 9 connector |
| 1 SUB-D 9 connector for channel 1 | |
| Local Signalling | CH0 Operating: 1 LED |
| CH1 Operating: 1 LED | |
| External Fault (I/O): 1 LED | |
| Internal Fault / Module Failure (ERR): 1 LED | |
| Master/Slave Status (MS): 1 LED | |
| Module Running (R): 1 LED | |
| Current Consumption | 500 mA at 5 V DC |
| Module Format | Standard |
| Dimensions (W x H x D) | 55 × 180 × 260 mm |
| Weight | 0.425 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the function of the TSXREY200 module?
A1: It serves as a remote rackmaster in a Bus X topology, managing communication between a local rack and remote I/O modules.
Q2: How many communication channels does the TSXREY200 support?
A2: The module supports 2 communication channels.
Q3: What type of connection interfaces does the TSXREY200 have?
A3: It is equipped with two SUB-D 9 connectors, one of which is dedicated to channel 1.
Q4: How is status information provided on the module?
A4: Status is indicated using six LEDs for channel operation, faults, mode, and running status.
Q5: What is the operating voltage and current requirement?
A5: It operates at 5 V DC with a current consumption of 500 mA.
Q6: What does the ERR LED indicate?
A6: The ERR LED indicates an internal fault or a failure within the module.
Q7: Can the TSXREY200 operate as both a master and a slave?
A7: Yes, it supports both master and slave roles depending on configuration.
Q8: What are the module’s dimensions and weight?
A8: The dimensions are 55 × 180 × 260 mm, and it weighs 0.425 kg.
