Technical Specifications
| Parameter | Description |
|---|---|
| Product Range | Modicon Premium Automation platform |
| Product Type | Extendable rack |
| Application | For multi-racks configuration |
| Number of Slots | 4 |
| Product Compatibility | I/O module, TSXPSY power supply, TSXP57 processor, Specific application module |
| Electrical Connection | 2 female SUB-D 9 connectors for remote X bus connection |
| Fixing Mode | 4 x M6 screws (panel mounting) or 35 mm DIN rail clips |
| Marking | CE marking |
| Dimensions (W x H x D) | 54 × 206 × 275 mm |
| Net Weight | 1.16 kg (2.56 lb) |
| Degree of Protection (IP) | IP20 |
| Pollution Degree | 2 |
| Standards | IEC 61131-2, UL 508, CSA C22.2 No 142, CSA C22.2 No 213 (Class I Div 2 Groups A, B, C, D), 89/336/EEC, 92/31/EEC, 93/68/EEC, 73/23/EEC |
| Certifications | RMRS, BV, ABS, RINA, LR, DNV, GL |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -25…70 °C (-13…158 °F) |
| Relative Humidity (Operation) | 10…95 % (non-condensing) |
| Relative Humidity (Storage) | 5…95 % (non-condensing) |
| Operating Altitude | 0…2000 m (0…6561.68 ft) |
| Protective Treatment | TC |
FAQ
FAQ
Q1: What is the maximum number of slots available in the TSXRKY4EX rack?
A1: The TSXRKY4EX provides 4 slots for module installation.
Q2: Which devices are compatible with the TSXRKY4EX?
A2: It is compatible with TSXP57 processors, TSXPSY power supplies, I/O modules, and specific application modules.
Q3: What type of connectors does the rack use for communication?
A3: It uses two female SUB-D 9 connectors for remote X bus communication.
Q4: How can the rack be mounted?
A4: The rack can be mounted either using 4 M6 screws (panel mounting) or clips on a 35 mm DIN rail.
Q5: What is the environmental protection rating of the product?
A5: The product has an IP20 rating and is suitable for pollution degree 2 environments.
Q6: What certifications does the TSXRKY4EX have for marine and industrial use?
A6: It holds certifications from RMRS, BV, ABS, RINA, LR, DNV, and GL.
Q7: What is the operating temperature range of the TSXRKY4EX?
A7: It operates in a temperature range from 0 to 60 °C (32 to 140 °F).
Q8: What are the dimensions and weight of the rack?
A8: The dimensions are 54 × 206 × 275 mm, and the weight is 1.16 kg.
